20 CM (8“) SUBWOOFER INCL. PROTECTION GRILLE

The visual highlight of every MG woofer is undoubtedly the newly designed, elegantly crafted aluminum cast basket with its delicate struts and large ventilation windows behind the spider.

Not only is the first look convincing, the technology in detail is also impressive: all woofers are characterized by a particularly long and even membrane stroke.  The moving mass (Mms) could also be kept low by using copper-clad aluminum voice coils (CCAW). All of the measures result in very favorable Thiele/Small parameters, so that the subwoofers are also very suitable for closed housings.  Anyone who attaches great importance to high impulse fidelity and cleanliness should choose this version.

If you like it fuller at the bottom, you should opt for bass reflex constructions. Due to their design, these can produce even more deep bass by utilizing the air in the housing with a specially tuned reflex channel. Here all three woofers unfold their potential and are easily able to play down to below 30 Hz.

Specifications

300 Watt RMS, 600 Watt max.

Impedance 2 + 2 Ohms

50 mm (2") Voice Coil

Sturdy Aluminum Cast Basket

Pre-assembled Protection Grille

2 x 1,4 kg (50 oz.) Magnet

Fs 46 Hz • Qts 0,44 • VAS 9,5 L

SPL 88 dB/2,38V/1m • Xmax +/- 19 mm

Installation Depth 138 mm
