8-CHANNEL CLASS D AMPLIFIER·1440 WATTS RMS

With the title "Most powerful 8-channel power amplifier in the world", the noble MUSWAY EIGHT100 makes a furious start in Car & Hifi 1/2022.

Test Review
Features

Class D Technology with very high efficiency

Selected and audiophile tuned components

Interference-free technology (ITF), high EMC

Intelligent High Level Input with Error Protection System

Auto Turn-On, Start Stop ready

Compact brushed aluminum heatsink

Compact Bass Level Remote Controller

Technology

Every channel pair can be bridged. Bridging amplifier channels to more than double the power.

EPS technology which prevents when connected to an OEM factory radio that no functions are impaired or error messages are written into the vehicle memory.

Pure amplification function allows you to fine tune the sound via DSP.

The amplifier can handle frequent power cycling from vehicles’ automatic start-stop systems, ensuring consistent sound quality even when the engine turns on and off repeatedly.

This feature eliminates the need for a separate remote turn-on wire, simplifying the installation process. It ensures that the amplifier is ready to operate whenever the audio system is in use.

Specifications

Power output(RMS) @ 14.4 VDC, 1% THD:

8x110 W /195W@ 4 Ω/2 Ω or 4x390 W @ 4 Ω bridged

Highpass Filter 50 - 5000 Hz (CH1/2 & CH5/6)

Highpass Filter 10 - 500 Hz (CH3/4 & CH7/8)

Lowpass Filter 50 - 5000 Hz (CH3/4 & CH7/8)

Bandpass Function (CH3/4 & CH7/8) Input Selector

Dimensions: 150 x 45 x 320 mm
