12-CHANNEL DSP WITH PC/APP CONTROL

The special feature of the TUNE12 is its ability to support both low-level and high-level audio sources simultaneously, allowing it to switch flexibly between them.

Test Review
Features Technology Specifications Download Related products
Features

Intelligent High Level Input (Error Protection System)

Start-Stop ready, Auto Turn-On

Burr-Brown converters (PCM3168A) and Analog Devices DSP (ADAU1452)

32bit, 295MIPS MHz DSP technology, controllable via new V3 PC software or Tunest App

Separately adjustable input sensitivity (CH1-8 high level, CH1-6 low level, AUX)

High quality full aluminum housing with glass plate

External Bluetooth® USB-Dongles BTS, BTS-HD & BTA2 for Audio Streaming & App Control (optional)

Digital remote control DRC1 with OLED display for controlling various DSP functions (optional)

Technology

The amplifier can handle frequent power cycling from vehicles’ automatic start-stop systems, ensuring consistent sound quality even when the engine turns on and off repeatedly.

This feature eliminates the need for a separate remote turn-on wire, simplifying the installation process. It ensures that the amplifier is ready to operate whenever the audio system is in use.

Specifications

8 x High Level Input 8 – 24 V RMS

6 x Low Level Input (RCA) 1 – 8 V RMS

1 x AUX Input/Stereo (RCA) 1 – 8 V RMS

1 x Optical Input/Stereo (PCM, 96 kHz / 24 bit)

1 x Coaxial lnput/Stereo (S/PDIF, 96 kHz / 24 bit)

12 x RCA Output 6,5 V RMS

Dimensions: 220 x 38 135 mm
